Wheel Mill Mixer

  • Model: 1400 / 1800 / 2000
  • Power: 5.5kw / 15kw / 18.5kw
  • Roller (width * diameter): 200*550mm / 250*700mm / 300*750mm

We have rich production experience, independent technical R & D team, and excellent quality of all products. In addition, we can provide customized production, overseas installation training and other services to our customers.

We're here to help: Easy ways to get the answers you need.

wheel mill mixer

1.Product introduction

It is a model that combines wheel milling and mixing designed according to the advantages of the latest foreign wheel milling and mixing equipment.

Utilize the gravity of the roller to crush and grind the materials, so that the materials can be fully integrated.

The equipment is composed of roller, roller, plate and drive part. Suitable for mixing powder and granular materials, such as carbon powder, coal powder, clay, refractory mud, tailing sand, slag, molding sand, etc.

Wheel mill mixer is widely used in carbon powder molding, coal powder molding, non-burning bricks, autoclaved bricks, refractory materials, ceramics, building materials and other industries.

wheel mill mixer

wheel mill mixer

wheel mill mixer structure diagram

wheel mill mixer structure diagram

2.Product Advantages

Wheel Mill Mixer has the advantages of good mixing effect, high production efficiency, convenient installation and maintenance, good airtightness, no environmental pollution, and strong adaptability. Various technical indicators are at the domestic advanced level.

3.Product Parameter

Parameter of Wheel Mill Mixer

Model Power(kw) Size(m) Roller (width * diameter)(mm)
1400 5.5 1.8*1.8*1.7 200*550
1800 15 2.1*2.1*1.85 250*700
2000 18.5 2.3*2.3*1.95 300*750
