What is carbonization?

Carbonization, also known as dry distillation, is a thermochemical processing method of solid fuels. The carbon-containing biomass raw materials are heated and decomposed into combustible gas, tar and charcoal products under the isolation of air.

How To Choose The Most Suitable Carbonization Furnace (step by step) 1

Note: In summary, the working principle of the carbonization furnace is similar, but the carbonization furnace selected is also different according to different materials, different finished product requirements and output requirements. To be engaged in the carbonization industry, it is particularly important to choose suitable carbonization furnace.

How to choose the suitable carbonization furnace?

1.Determine your materials

1.1 Hoisting carbonization furnace and Horizontal carbonization furnaceapplicable material:

How To Choose The Most Suitable Carbonization Furnace (step by step) 2

1.2 Sawdust carbonization machine and Continuous carbonization furnaceapplicable material:

How To Choose The Most Suitable Carbonization Furnace (step by step) 3

2.Determine your finished product requirements

2.1 Hoisting carbonization furnace and Horizontal carbonization furnace finished

product:

How To Choose The Most Suitable Carbonization Furnace (step by step) 4

2.2 Sawdust carbonization machine and Continuous carbonization furnace finished product:

How To Choose The Most Suitable Carbonization Furnace (step by step) 5

3.Determine your capacity

ProductDaily output
Hoisting carbonization furnaceMin::1t/d           Max:6t/d
Horizontal carbonization furnace0.8-1.5t/d   (Models can be customized)
Sawdust carbonization machine150-200kg/h
Continuous carbonization furnace600-1000kg/h

4.Determine your voltage capacity

ProductTotal power
Hoisting carbonization furnace2.25kw-7.7kw
Horizontal carbonization furnace3kw
Sawdust carbonization machine11kw
Continuous carbonization furnace28.35kw-47.35kw

5. Determine the area of your site

ProductArea
Hoisting carbonization furnace30-120㎡
Horizontal carbonization furnace50-60㎡
Sawdust carbonization machine40-50㎡
Continuous carbonization furnace180-200㎡

We can match different charcoal making machine production lines according to your finished product requirements, and provide free 3D design drawings, so that you have a clearer understanding.
